Bendix Internally Geared Hubs

Image: bendix2speed.jpg

Bendix 2-Speed Coaster Brake with Shifter

Image: bendixredband.jpg

Bendix Kick-Back 2-Speed Coaster Brake (Red Band)

Image: bendixyellowband.jpg

Bendix Kick-Back 2-Speed Coaster Brake (Yellow Band, underdrive)

Below is another yellow band from a 1960s Schwinn Krate.

Image: bendixyellowband2.jpg

Image: axlelength.jpg Image: valbendix.jpg

Use of reproduction tool to set axle extension on left side.

Val Kleitz overhauling the above hub.
